4 External Antennas HGU Router GPON ONU 4GE Home Gateway Unit 240VAC 50Hz 0.36KG

Name: 4 External Antennas HGU Router GPON ONU 4GE Home Gateway Unit 240VAC 50Hz 036KG
Brand: BEHOME
Price: 1 USD

Quality 4 External Antennas HGU Router GPON ONU 4GE Home Gateway Unit 240VAC 50Hz 0.36KG wholesale

Brand Name : BEHOME

Model Number : BHU2104BW

MOQ : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 3000PCS PER MONTH

Delivery Time : 1 month if no any stock

Place of Origin : sichuan

Certification : ISO14001 ISO2000 ISO45001

Price : Negotiable

MODEL : BHU2104BW

brand : BEHOME

origin : sichuan

USB Interface : USB 2.0

Contact Now

Overview

By introducing latest fiber GPON access technology, The BHU2104BW GPON ONU Router brings carrier class high-end networking solution for advanced triple play services. It compliant with ITU-T G.984 standard, dual-band wireless for combined connection speeds of up to 1200 Mbps(867 Mbps on 5GHz and 300 Mbps on 2.4 GHz) , Layer 2/3, and high quality VoIP as well, BHU2104BW GPON ONU Router support the comprehensive triple-play services, including voice, video (IPTV or VoD), and high-speed internet access service.

BHU2104BW XPON(4GE) GPON HGU

EPON Interface
Rate	Upsteam: 1.25Gbps Downsteam: 1.25Gbps
Interface standard	IEEE802.3ah EPON standard
Launch power	Min: 0dBm Max: +4dBm
Sensitivity	-27dBm
Input Power Overload	-7dBm
Service Interface
EPON Interface	1 EPON Port
Data Interface	4 GE
POTS Interface	1 FXS Port
WIFI Interface	IEEE 802.11 ac/n/g/b/a wireless LAN
USB Interface	USB 2.0
Antenna Type	4 external antennas
Environmental conditions
Storage	temperature -10 to 70°C, rel. humidity 10–90% (non-condensing)
Operation	temperature 0 to 45°C, rel. humidity 10–90% (non-condensing)
Power Supply and Consumption
Power Adaptor	Input: 100 to 240 V AC, 50/60 Hz; Output: 12 V, 1.5A
Consumption	≤12W
Physical specifications
Dimensions	253mm×153mm×33mm(L×W×H)
Weight	0.36KG

4 External Antennas HGU Router GPON ONU 4GE Home Gateway Unit 240VAC 50Hz 0.36KG

Recommand Devices List
Item Code	Item Name	Decription
BHU2104	Simple GPON ONU without WIFI	1GE+3FE
BHU2104W	XPON ONU(GPON/EPON/XPON/10GPON)	2GE+2FE+1FXS+1USB
BHU2104BW	GPON ONU	4GE+2FXS
BHU2000	Wifi6	1GE WAN+3GE LAN
BOR1000AN	Economic Optical Receiver
BOR1000BW	Economic Optical Receiver with WDM
BOR1000BN	White Optical Receiver
BOR1000DW	White Optical Receiver with WDM
